The working area of 1300×2500mm/1500*3000mm can meet the demands of engraving and cutting on large scale garments and cloth, leather, wood, acrylic, and paper industry.
Suitable for industries such as billboards, artistic gifts, crystal ornaments, paper cut engraving, bamboo embossment, printing, garments and leather industries, embroidery, interior decoration, frame fabrication and etc.
Double color boards, acrylic, glass, wood planks, bamboo, foam, MDF, rubber, plastic, garments, paper, leather, marble, granite, tiles, and etc...
| Model | FLC1325 |
| Laser-type | 10.6um CO2 glass laser tube w/ water-cooling |
| Laser power | 80W-300W |
| Working area | 1300*2500mm |
| Max Engraving speed: | 0-50, 000mm/min |
| Max cutting speed | 0-24, 000mm/min |
| Laser output control | 1-100% software setting |
| Location precision | Less than 0.01mm |
| Highest scanning precision | 2500DPI |
| Operating temperature | 0 - 45 |
| Operating humidity | 5- 95% non-condensing |
| Minimum shaping character | English 1.0 x 1.0mm |
| Graphic format supported | HPGL, BMP, JPEG, PLT, DST, DXF, and AI ... |
| Driving system | Stepper |
| Cooling mode | Water-cooling and protection system |
| Auxiliary equipments | Exhaust-fans, air-exhaust pipe, air pump, chiller |
| Controller | DSP |
| Compatible Software | CorelDraw, AutoCAD, Photoshop, TAJIMA |
| Slope Engraving | Can be easily designed within the "Grade Engrave" function. |
| Color separation | Uses color property to set function, speed, and laser power |
